TSUM V59MS_T9B Software Free Download

TSUM V59MS_T9B TV Board

TSUM V59MS_T9B is an analog LCD/LED TV Control Board that is suitable for the Asia Pacific and the Middle East Markets. It can support 32-inch to 50-Inches LED panels which a resolution is up to 1920×1080. Its USB interface supports Multimedia Playback and Software Upgrades as well. TUSMV59.T9B has multiple HDMI ports that support 1.4 and its HDCP support 1.1. TSUM V59MS_T9B is compatible with Non-HD and FHD LCD/LED panel screens. TSUM V59MS-T9B is widescreen-supported and also has a multi-language option. TSUM V59MS-T9B has its special feature of Dual AV extendable. TSUM V59MS-T9B software collection is given below for free download.

General Specifications:

Board Make: China

Board Model: TSUM V59MS_T9B

Main Chipset: TSUMV59XUS

TV System: PAL/SECAM/NTSC

Panel Interface: Single-channel or Dual-channel LVDS

Key Button Functions: CH-/CH+/MENU/VOL-/VOL+Souce/Power

Multi-Language: Yes

Input/Output Ports: HDMI, VGA, AV, USB, RF TV interface and Earphone Out

Audio O/P Power: 2 x 8 Watt (8 ohms)

Panel Voltage: +5V/+12V DC (Default 12V)

USB Port: Yes (Firmware Upgrade and Multimedia Playback Support)

IR Control: Yes (Controllable by Remote Control)

Electrical Parameters:

Working Input Voltage: AC220 Volt

Maximum Current: 5000mA (Without Panel)

Standby Power: <0.5W

Maximum Current for USB: 500mA

Flash IC: 4MB

Firmware Type: Backup Dump

Note: Following firmware collection is a Backup Dump saved from working LED TVs that can be loaded by a programmer. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.

How to Download Firmware File:

Download your required file of the following firmware and then extract it you will get the folder. Now you can write the file with a programming tool. for More Detail about the download, process watch the video Click Here

TSUM V59MS_T9B Firmware Collection Free Download Here :

S.NO.	BOARD/DESCRIPTION	DOWNLOAD LINK
1	TSUM V59MS_T9B_1366x768_ERGO_DUMP	Download
2	TSUM V59MS_T9B_1920x1080_ECOSTAR_DUMP	Download
3	TSUM V59MS_T9B_1920x1080_MASANO_DUMP	Download
4	TSUM V59MS_T9B_1920x1080_MAXIPOWER_DUMP	Download
5	TSUM V59MS_T9B_1920x1080_TCL_DUMP	Download
