TP.V56T.PB706 LED TV Board
TP.V56T.PB706 is a simple ATV Drive Board designed for LCD/LED TVs. This Board is suitable for the Asia Pacific and the Middle East markets. This Combo Board has the integration of the main power module, LED Backlight Inverter Circuit, and ATV Card Also in a single piece of a motherboard. This has all the features as per the latest requirements like HDMI input, USB interface, PC input, Component Input, TV, and Headphone jack. TP.V56T.PB706 is compatible with 32 inches panel screens.
General Specifications:
Brand/Mark: Universal HD Three-in-One Board
Model: TP.V56T.PB706
Main Chip: TSUMV56
Product: LED TV
LED Backlight Capacity: 350mA
LED Backlight: 25w
Flash IC: 4Mb
Screen supported: 32 inch
Resolution: Up to 1920×1080
Panel Voltage: 12V
Power Input: 220V AC
Tuner:
Mirror Option: Optional
Service Code:
Input
Note: The following given software/firmware is USB upgradeable and Backup Dump Files. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of loading/installing the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download:
Download the following given firmware/software and then extract you will get the folder. Now copy the files to USB. for More Detail about the download process watch the video Click Here
TP.V56T.PB706 firmware for free download:
- TP-V56T-PB706_1366x768_ERGO_DUMP
- TP-V56T-PB706_1366x768_KORYO_DUMP
- TP-V56T-PB706_1366x768_UNIONAIRE_DUMP
- TP-V56T-PB706_1366x768_VU_DUMP
For video tutorials, visit “Kazmi Elecom” my youtube channel.
