TP.MS608.P82 Smart LED TV Board
TP.MS608.P82 is a smart Android LED TV motherboard with a special feature of 3D. The users can enjoy playing 3D movies of their own choice with this board. This is a combo three-in-one motherboard that has a built-in TV tuner. A 220-volt power supply and backlight driver circuit modules are also built into this motherboard with a single PCB. A single solution for all the items required for the panel screen. The maximum supported resolution of this board is 1920×1080 Full HD and it can support 32 to 55-inch screen panels.
TP.MS608.P82 has some smart applications built into its software that can be beneficial for the user. Multiple input connectivity interfaces for user convenience such as VGA input connection that is very helpful for the connectivity of a laptop or computer with a big screen, dual HDMI inputs that can support Full HD types of equipment for excellent results, dual USB input for playing multimedia files and software upgrade purpose. Dual RCA, Wifi, and RJ45 ethernet connection for wired internet are also given.
General Specifications:
Brand/Mark: China Universal Triple Network Drive Board
Main Board: TP.MS608.P82
OS: Android 4.4
CPU: Dual Core
Size: 18.5 * 21 cm
Back Light V/C : 70v-90v 450mA 45w
Ram: 512 Mb DDR
Rom: 4 Gb eMMC
Resolution: up to 1920×1080 (26″ to 55″)
Service Code:
Input/Source 1147
Caution:
All the pictures and specification details related to TP.MS608.P82 in this post are for reference only. If you are a user and do not have any repair experience, it is better to visit the nearest technician first without loading the software/firmware. Sometimes, the fault is different based on the visual observations. So, please do not try it at home. If the LED TV is slow then reset it to Factory Default only.
Pros:
There are many advantages to installing the given TP.MS608.P82 USB software or eMMC backup dump file. A few benefits are described below:
- The dead board or stuck-on logo can be recovered and operational by loading the given USB software or EMMC backup file
- Remote and Logo may change at your own choice to satisfy the customer
- Money saving instead of changing the mainboard
- Time-saving instead of arranging a new board
Cons:
There may be some disadvantages to installing the given TP.MS608.P82 USB software or backup dump file. But it depends on the technician or user, as per his understanding. A few drawbacks are described below:
- The working board may go to the standby position
- Remote Control may not work and the Logo may change by writing the given software
- Panel screen parameters may be changed
TP.MS608.P82 Android Version Upgrade:
Please note that the installed version in this board is the final version and can not be upgraded to newest version. So, no need to upgrade the software if the board is working normally. Only if, the default software malfunctions due to some bugs will the manufacturer provide the software update. Otherwise, no version update is issued.
TP.MS608.P82 EMMC Backup:
This board has a 4GB eMMC chip. you can read the EMMC backup by Pendrive but for writing a backup of EMMC you should jtag the mainboard TP.MS608.P82 and write by a programming tool. Be careful while writing emmc backup file, if the board is on standby light due to wrong software or incomplete installation then you can do it, otherwise, it is on standby or red light due to hardware fault. So, first trace the fault. In this case, no need to write emmc backup.
TP.MS608.P82 Board Replacement:
If this 3D board is completely dead and has no chance to repair then replace the same board as already installed. And if the same board is not available on the market then search for the board that has the same specifications, the newest Android version, and the latest features to avoid any difficulties. If the backlight module is faulty in the combo board then you can install only the backlight module separately then no need to change the whole board.
Note: The following firmware is a USB bootable and EMC backup file. Kazmi Elecom Team is not responsible for any damage/loss caused by uploading/downloading the firmware. First, check and verify the main board then install software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or facing any issues during firmware installation then visit and read here first.
How to Download:
Download all parts of the following given firmware/software and then extract any one of them you will get the folder. Now copy the files to USB. For more Details about the download process watch the video Click Here
How to Update:
- Copy the upgrade file into USB Disk
- Plug in the USB Disk into USB Interface Port of Main TV Card
- Power on the TV
- Wait for the LED light to start Flashing
- If the LED light starts flashing, it means TV is entered in Upgrade Mode
- Within in 2 minutes, the process will be done and LED light will flash speedily. It’s Done, Now Turn off the power and again turn on the TV.
TP.MS608.P82 firmware for free download:
| S.NO. | BOARD/DESCRIPTION | D.LINK.1 |
|---|---|---|
| 1 | TP.MS608.P82_1920x1080_Samsung_Tested.part1 | Download |
| TP.MS608.P82_1920x1080_Samsung_Tested.part2 | Download | |
| TP.MS608.P82_1920x1080_Samsung_Tested.part3 | Download | |
| TP.MS608.P82_1920x1080_Samsung_Tested.part4 | Download | |
| TP.MS608.P82_1920x1080_Samsung_Tested.part5 | Download | |
| 2 | TP.MS608.P82_1920x1080_CAL.part01 | Download |
| TP.MS608.P82_1920x1080_CAL.part02 | Download | |
| TP.MS608.P82_1920x1080_CAL.part03 | Download | |
| TP.MS608.P82_1920x1080_CAL.part04 | Download | |
| TP.MS608.P82_1920x1080_CAL.part05 | Download | |
| 3 | TP.MS608.P82_1920x1080_Panda.part01 | Download |
| TP.MS608.P82_1920x1080_Panda.part02 | Download | |
| TP.MS608.P82_1920x1080_Panda.part03 | Download | |
| TP.MS608.P82_1920x1080_Panda.part04 | Download | |
| TP.MS608.P82_1920x1080_Panda.part05 | Download | |
| 4 | TP.MS608.P82_1920x1080_Starlight.part01 | Download |
| TP.MS608.P82_1920x1080_Starlight.part02 | Download | |
| TP.MS608.P82_1920x1080_Starlight.part03 | Download | |
| TP.MS608.P82_1920x1080_Starlight.part04 | Download | |
| TP.MS608.P82_1920x1080_Starlight.part05 | Download | |
| 5 | TP.MS608.P82_1920x1080_Sony KDL-40X9000_Tested.part01 | Download |
| TP.MS608.P82_1920x1080_Sony KDL-40X9000_Tested.part02 | Download | |
| TP.MS608.P82_1920x1080_Sony KDL-40X9000_Tested.part03 | Download | |
| TP.MS608.P82_1920x1080_Sony KDL-40X9000_Tested.part04 | Download | |
| TP.MS608.P82_1920x1080_Sony KDL-40X9000_Tested.part05 | Download |
