TP.HV553.PB801 Android Smart Board
TP.HV553.PB801 is an Intelligent smart 4K network driver LED TV board with a support resolution of 3840×2160. TP_HV553_PB801 is dedicated to 60 Hz screens. It is a combo board. Smart UHD TV With Android Platform and great features to entertain ultra HD Wide Screen with better to work SMART. TP-HV553-PB801 has the full features of input interface connectivity. It has multiple ports like HDMI, AV, Headphones, VGA interface, USB ports, and RJ45 Ethernet port for wired internet connectivity. Its USB interface can be used for Firmware upgrades as well as for multimedia playback.
TP HV553 PB801 is a digital and analog TV board, it can receive analogtelevision (PAL/SECAM/NTSC) and digital television (DVB-T/T2/C/S) signals. TP.HV553.PB801 Firmware file is given below for Technician’s support.
General Features & Specifications:
Brand/Make: LCD/LED 4K Smart Driver Board
Model: TP.HV553.PB801
Supported Resolution: 3840×2160 UHD 4K
Screen Format: 16:9
Chipset: hi3751v553
Operating System: Android 9.0
CPU: A73*2 Dual-core 800Mpbs
GPU: Mali-450*4
RAM: 1GB DDR3
ROM: 8Gb
Sound Output: 8Wx2
Backlight Current: 600mA
Tuner: SI2159
RF TUNER: DVB-T/T2/C/S/S2/(S/S2 option)
Video System: PAL/SECAM/NTSC
Power Input: 100-240 ~ 50/60Hz
Power Consumption: 115W (may be different according to panel)
Standby Power: 0.5W
Note: The following given software for Technician’s support. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download TP.HV553.PB801 Firmware Files:
Download all parts of the following given firmware/software and then extract any one of them you will get the folder. Now copy the files to USB. for More Detail about the download process watch the video Click Here
TP.HV553.PB801 firmware file for free download:
| S.NO. | BOARD/DESCRIPTION | DOWNLOAD LINK |
|---|---|---|
| 1 | TP.HV553.PB801_3840x2160_1G_8G_MMX_USB.part01 | Download |
| TP.HV553.PB801_3840x2160_1G_8G_MMX_USB.part02 | Download | |
| TP.HV553.PB801_3840x2160_1G_8G_MMX_USB.part03 | Download |
For video tutorials, visit “Kazmi Elecom” my youtube channel.
