KK.V35X.801A Smart Android Board
KK.V35X.801A is an Android network driver smart LED TV board with an FHD resolution of 1920×1080. KK_V35X_801A has a powerful wifi system. Smart FHD TV With Latest Android Platform version 9.0 and great features to entertain Full HD Wide Screen with better to work SMART. KK V35X 801A Smart Board has multiple ports A/V, USB interface Ports, and many HDMI ports in addition to the VGA interface for computers.
KK-V35X-801A also has a LAN/RJ45 Connector interface port for the wired internet network. KK.V35X.801A is a Combo Network Triple play board that has a Digital TV tuner built-in in it (DTMB/DVB-C/ATSC/ISDB-T). The Graphics and Sound quality of the KK.V35X.801A Android board is very good and the Response rate is very efficient. KK.V35X.801A China smart network board can support up to 42″ LED Panels. KK.V35X.801A firmware file is available for the technician’s support.
General Specifications:
Brand/Mark: Main Board (Android WIFI Network Drive Smart Board)
Main Board: KK.V35X.801A
Main Chipset: Hi3751V350
Operating System: Android 9
CPU: Multi Core Arm Cortex A53 64-bit
GPU: Multi-Core Mali-T450
CPU Frequency: 1.2GHz
GPU Frequency: 432MHz
RAM: 512MB
ROM: 4 Gb
Resolution: up to 1920×1080
Screen Size supported: 32 to 42 Inch
Audio Output power: 2x8W
Mirror Mode: Yes
Logo Change: Yes
Tuner:
Input Voltage: 200-240V AC
Firmware Name: allupgrade_V3500N0N_4G_512M_75.bin
Firmware Version:
KKV35X_India_V35X_801A_Hi3751V350_DMO-eng 9_MI200402ZZY001_STAR_ASIA_V35X801A_600MA
Panel Name: LVDS_VGA_1366x768_60Hz_2D
Firmware Type: USB Updateable Firmware
Product User: Star Asia
Note The following given Software/firmware is USB upgradeable. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download Firmware Files:
Download all parts of the following given firmware/Software and then extract any one of them you will get the folder. Now copy the files to USB. For more Details about the download process watch the video Click Here
KK.V35X.801A firmware file for free download:
