CV6886H-A UHD Smart Board
CV6886H-A is a 4K UHD LED TV driver board which a support resolution of 3840×2160. CV6886H_A is dedicated to 50/60 Hz screens. UHD TV With features to entertain ultra HD Wide-Screen. CV6886H_A has the full features of input interface connectivity. It has multiple ports like HDMI, AV, Headphones, VGA interface, Scart, Coaxial Out, USB ports, and RJ45 Ethernet port for wired internet connectivity. Its USB interface can be used for Firmware upgrades as well as for multimedia playback.
CV6886H.A is a digital and analog TV board, it can receive analogtelevision (PAL/SECAM) and digital television (DVB-T) signals. The CV6886H_A USB Upgrade Firmware file is given below for Technician’s support. CV6886H.A Mainboard is used for Haier Brands 4K Ultra LED TVs.
Specifications & Features:
Model Name: CV6886H-A
Resolution: 3840×2160
Processor: Quad Core
Android Version: 9
RAM: 1.5G
ROM: 8G
Aspect Ratio: 16:09
Audio Power Output: 16w (8×2)
System: PAL//SECAM
Tuner: ATV and DTV (Optional)
HDMI: 4
USB Ports: 2
Wifi: Yes
Bluetooth: Yes
Power Rating: 100V~240V 50Hz/60Hz
Power Consumption: 145Watt
Standby Power: 0.5W
Firmware: upgrade_no_tvcertificate.pkg
Firmware Type: USB Upgrade Firmware & EMMC Backup
Note: The following given software/firmware is USB upgradeable. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download:
Download all parts of the following given firmware/software and then extract any one of them you will get the folder. Now copy the files to USB. for More Detail about the download process watch the video Click Here
CV6886H-A Firmware files for free download:
| S.NO. | BOARD/DESCRIPTION | DOWNLOAD LINK |
|---|---|---|
| 1 | CV688H-A_3840X2160_1.5G_8G_HAIER.part1 | Download |
| CV688H-A_3840X2160_1.5G_8G_HAIER.part2 | Download | |
| CV688H-A_3840X2160_1.5G_8G_HAIER.part3 | Download | |
| 2 | CV688H-A_3840X2160_EMMC_HAIER.part1 | Download |
| CV688H-A_3840X2160_EMMC_HAIER.part2 | Download | |
| CV688H-A_3840X2160_EMMC_HAIER.part3 | Download |
I have a CV6886H-C Motherboard in a 50″ Bolva 50MVT20
Do you know where I can get the firmware? The Browser date is 2018 and some videos
will not play as it says it is out of date.
can not update. change motherboard for latest version
Sir cv6886h ko USB set install karneka torika bolo.. Help me sir
https://www.kazmielecom.tech/how-to-load-firmware/
CV6886
Sir mujhe cv6886h a software chaie tha USB se install karta tha thoda help karega sir
ok
HELLO SIR I HAVE HAIR MODLE LE58K6600UG BOARD NO CV6886H-A . KYA MAI YAI FILE INSTAL KAR SAKTA HU ISS BOARD MAI.? BOARD NO SAME HAI
han kar sakte henper apne karni kion hy. masla kia hy??
