CV59L-L Universal Board
CV59L-L Software collection is shared in this post for the technician’s support.
Basic Info:
Model No. CV59L-L
Main Chipset: TSUMV59XU-Z1
Trademark:
Display Format: up to 1920×1080
Aspect Ratio: 4:3, 16:9 & 16:10
Board Size: 168.00 X 42.0 (mm)
General Specifications:
TV System: PAL/SECAM/NTSC
Panel Interface: Single channel or Dual channel LVDS
Key Button Functions: CH-/CH+/MENU/VOL-/VOL+Souce/Power
Multi-Language OSD: Yes
Input/Output Ports: HDMI, VGA, AV, SCART, USB, RF TV interface and Earphone Out
Audio O/P Power: 2 x 3 Watt (8 ohm)
Panel Voltage: +3.3V/+5V/+12V DC (jumping cap setting)
USB Port: Yes (Firmware Upgrade and Multimedia Playback Support)
USB File Format: Audio (Mp3, wma, m4a/aac), Video (avi, mp4, ts/trp, mkv/mov, mpg, dat, vob, rm/rmvb), Picture (Jpg, jpeg, bmp, png), Text (text)
IR Control: Yes (Controllable by Remote Control)
Electrical Parameters:
Working Input Voltage: DC +12 Volt
Maximum Current: 2000mA (Without Panel)
Standby Power: <0.2W (for the motherboard only)
Maximum Current for USB: 500mA
Note: The following given software/firmware is USB upgradeable. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of loading/installing the firmware. If you are new and do not have enough knowledge of loading or installing software/firmware or dump files then read here first.
How to Download:
Download the following given firmware/software and then extract you will get the folder. Now copy the files to USB. for More Detail about the download process watch the video Click Here
CV59L-L Software Free Download Here :
| S.NO. | BOARD/DESCRIPTION | DOWNLOAD LINK |
|---|---|---|
| 1 | CVMV59L-L_15 INCH_DUMP | Download |
| 2 | CVMV59L-L_17&19 INCH_USB | Download |
| 3 | CVMV59L-L_22 INCH_DUMP | Download |
| 4 | CVMV59L-L_22 INCH_USB | Download |
| 5 | CVMV59L-L_1280x1024_DUMP | Download |
| 6 | CVMV59L-L_1366x768_DUMP | Download |
| 7 | CVMV59L-L_1400x1050_DUMP | Download |
| 8 | CVMV59L-L_1680x1050_DUMP | Download |
| 9 | CVMV59L-L_1920X1080_DUMP | Download |
| 10 | CVMV59L-L_ALL | Download |
For video tutorials, visit “Kazmi Elecom” my youtube channel.
