CV59L-C LED TV Board
CV59L-C is a simple ATV Driver Motherboard designed for LCD/LED TVs. CV59L_C board is suitable for the Asia Pacific and the Middle East markets.CV59L.C is a Non-Combo Board. The main power module and LED Backlight Inverter Circuit module are required separately but the ATV Card is builtin into this motherboard. CV59L C has all the features as per the latest requirements like HDMI input, USB interface, PC input, Component Input, TV, and Scart.CV59L-C firmware files are given below for the technician’s support.
General Specifications:
Brand/Mark: Universal Board
Model: CV59L_C
Main Chip: TSUMV59XE-Z1/TSUMV59XU-Z1
Product: LED TV
LED Backlight: mA
Flash IC: 4Mb
Sound Chip: 1517P
Tuner IC: 5158
Screen supported: 15-24 inch
Resolution: Up to 1920×1080
Panel Voltage: 5V, 12V
Power Input: 220V AC
Service Code:
Source/Input+2580
Note: The following firmware is a backup file. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. If you are facing any issues during firmware installation then visit and read here first.
How to Download Firmware Files:
Download all parts of the following firmware and then extract any one of them you will get the folder. Now copy the files to USB. for More Detail about the download process watch the video Click Here
CV59L-C firmware for free download:
| S.NO. | BOARD/DESCRIPTION | DOWNLOAD LINK |
|---|---|---|
| 1 | CV59L-C_1366x768_MICROMAX_DUMP | Download |
| 2 | CV59L-C_1366x768_SAMSUNG_DUMP | Download |
| 3 | CV59L-C_1366x768_SONY_DUMP | Download |
| 4 | CV59L-C_1366x768_SONY_USB | Download |
| 5 | CV59L-C_1366x768_TELEFUNKEN_DUMP | Download |
| 6 | CV59L-C_1920x1080_22-INCH_DUMP | Download |
| 7 | CV59L-C_1920x1080_ELENBERG_DUMP | Download |
| 8 | CV59L-C_1920x1080_SAMSUNG_DUMP | Download |
| 9 | CV59L-C_1920x1080_SAMSUNG_USB | Download |
| 10 | CV59L-C_1920x1080_SONY_DUMP | Download |
| 11 | CV59L-C_1366x768_CROWN_DUMP | Download |
| 12 | CV59L-C_1366x768_DNS_DUMP | Download |
| 13 | CV59L-C_1366x768_ELENBERG_DUMP | Download |
