5800-A8R20T-0P20 Software Free Download

5800-A8R20T-0P20 FHD Smart Board

5800-A8R20T-0P20 is a Full HD smart Android LCD LED TV motherboard with a maximum supported resolution of 1920×1080 Full High Definition 1080 Pixels. This board is a Non-Combo board. Three-in-one features are not available on this board. The user needs a separate main input power supply module and backlight inverter driver module to complete the LED TV setup. While the cable TV tuner is built into a main PCB. This board has a Realtek main chipset and 8GB ROM storage EMMC Nand Flash memory capacity.

Download Here

5800-A8R20T-0P20 is a smart Android board with version 4.4.2. It has inbuilt with several input and output connectivity interfaces such as Dual USB input slots, triple HDMI input ports, VGA interface for PC and Laptop connectivity, Component input/output, coaxial out, Headphones out jack, cable TV tuner, and RJ45 ethernet connection for fast wired internet connectivity to get smooth browsing results.

5800-A7M42G-0P00 General Information:

Board Model: 5800-A8R20T-0P20 VER01.00

Main Chipset: Realtek

CPU: Quad-Core

GPU: Dual-Core

Operating System: Android 4.4.2

Resolution: 1920×1080

Audio Power: 2x6W (12 watts)

Backlight Current: 380-620 mA

Backlight Voltage Range: 40-114 Volt

USB Ports: 2

HDMI Ports: 3

CI: No

Component: Yes

RJ45: Yes

Analog Tuner: PAL, SECAM, NTSC

Digital Tuner:

Wifi: Yes

Mira-Cast:

Memory (RAM): 1GB DRAM

Storage (ROM): 8 GB EMMC Flash

EMMC: THGBMFG6C1LBAIL

Power Rating: 110V~240V 50/60Hz

Power Consumption: 65Watt

Firmware Name:

Firmware Type: USB Bootable and EMMC Backup Dump

Product Users: DAEWOO

Compatible Versions:

DLE-43H5100-DPB
DLE-49H5100-DPB
DLE-55H5100-DPB
DLE-49G5000-DPB

5800-A8R20T-0P20 Technical Specifications:

Resolution 1920×1080 Full HD
HD support HD
LED backlight DLEDD
Response time 8 ms
Display scale 16:09
Stereo sound there is / there is
Matrix type LED
Refresh rate 60 Hz
Processor frame Quad core
GPU Dual core
OS version Smart
RAM (DRAM) 1GB
ROM (Flash) 8GB
WIFI 2T2R
HDMI 2.0 (HDCP 2.2) 2
HDMI CEC (T-link) Full
Caption (Subtitle) Yes
USB HID support Yes
USB channel list clone Yes
USB 2.0 2
Teletext there is
ATV PAL, SECAM, NTSC
DTV DVB-T, DVB-T2, DVB-C, DVB-S, DVB-S2
Sound power 6w+6w
Acoustic system Buffer speakers
DOLBY DIGITAL there is
Supported formats MP3, WMA, MPEG4, MKV, JPEG
Social Applications Yes
Web browser Yes
Processor Quad Core
WiFi sharing Yes

How to Write 5800-A8R20T-0P20 EMMC Backup:

Download the given 5800-A7M42G-0P00 EMMC backup shared in this post below
Note the EMMC Pinouts (D0, CMD, CLK) in the given picture above
Jtag the mainboard with the Programming Tool
Write the EMMC data
Done.

Note: The following 5800-A8R20T-0P20 firmware is USB bootable and a backup dump file. Kazmi Elecom Team is not responsible for any type of damage/loss as a result of uploading/downloading the firmware. First, check and verify the main board then install software. If you are new and do not have enough knowledge of loading/installing software/firmware or dump files, or facing any issues during firmware installation then visit and read here first.
